John Deere
series 5M
Models: 5090M – 5100M – 5115M
Standard equipment:
Engine
4-Cylinder JOHN DEERE PowerTech PWX engine, 4525 ccm displacement,
turbocharger, Intercooler, Tier IIIB, 4V-CommonRail, 90 / 100 / 115 HP rated power,
Diesel-ONLY Technology, fuel tank 177 ltr., exhaust downwards
Transmission
PTO
540/540E/1000, electrohydraulic actuation
Hydraulic
OpenCenter with tandem pump 70 l/min. + 24 l/min., 2 double-acting control units, mechanical lower link control, adjustable lift struts left and right, lower link with quick coupler, top link with catch arm, automatic stabilizing strut, leakage oil collection
container, power lift cylinder 70 mm
Tires
420/85R30 – 320/85R24 Mitas. Other tire variants possible
Cabin
Special hop cabin, with integrated safety frame, air conditioning and heating, opening front and rear window with wiper and washer system, glass roof hatch, vine deflector bar, 2 x H3 double-beam work lights at the front, 2 x H3 double-beam work lights at
the rear, passenger seat, toolbox, digital display, air-suspended premium seat, radio installation kit
Optional
- Radio
- Electronic hitch control (EHR)
- 2 adjustable H4 headlights
- Dual-circuit air brake
- 3rd double-acting control unit
- Tires 480/70R30 – 375/70R20
- Front hydraulic and front PTO
- Front loader
